HT11A系列非对称式三辊卷板机系列
空心辊非对称式卷板机可能的特点（可根据实际情况进一步完善或调整）：
卷制能力强：能够对不同厚度和材质的板材进行卷制，适应多种规格的板材加工需求。 非对称结构优势：非对称的辊子布置，使得板材在卷制过程中能够实现特殊的弯曲效果，适用于一些特殊形状的工件卷制，如锥形、非圆形等。 空心辊特性：空心辊设计可减轻设备重量，同时在一些情况下，空心辊内部可以安装相关的检测或辅助装置，提升卷板机的性能和功能。 精度较高：配备先进的控制系统和高精度的传动机构，能够精确控制板材的弯曲角度和曲率，保证卷制工件的精度和质量。 操作便捷：具有人机交互界面，操作人员可以方便地设置卷板机的各项参数，实现自动化或半自动化操作，提高工作效率。 维护方便：结构设计合理，关键部件易于拆卸和维护，减少设备的维护成本和停机时间。 安全性能好：设置了多种安全保护装置，如过载保护、限位保护等，保障操作人员和设备的安全。 可扩展性：可以根据客户的不同需求，增加或更换相关的功能部件，如自动送料装置、端部预弯装置等，满足多样化的生产需求
性能特点： 该机结构型式为经济型三辊对称式，上辊在两下辊中央对称位置作垂直升降运动，通过丝杆丝母蜗杆传动而获得，两下辊作旋转运动，通过减速机的输出齿轮与下辊齿轮啮合，为卷制板材提供扭矩。该机缺点是板材端部需借助其它设备进行预弯。
HT11A Series Asymmetric Three-roll Plate Bending Machine Series
Characteristics of the Asymmetric Plate Bending Machine with Hollow Roll (can be further improved or adjusted according to the actual situation):
Strong Rolling Capacity: It can roll plates of different thicknesses and materials, meeting the processing requirements of plates of various specifications. Advantages of the Asymmetric Structure: The arrangement of the asymmetric rollers enables the plate to achieve special bending effects during the rolling process, and it is suitable for rolling workpieces of special shapes, such as cones and non-circular shapes. Characteristics of the Hollow Roll: The design of the hollow roll can reduce the weight of the equipment. In some cases, relevant detection or auxiliary devices can be installed inside the hollow roll to enhance the performance and functions of the plate bending machine. High Precision: Equipped with an advanced control system and a high-precision transmission mechanism, it can precisely control the bending angle and curvature of the plate to ensure the precision and quality of the rolled workpiece. Easy Operation: It has a human-machine interaction interface, allowing operators to conveniently set various parameters of the plate bending machine and achieve automated or semi-automated operation, improving work efficiency. Easy Maintenance: With a reasonable structural design, the key components are easy to disassemble and maintain, reducing the maintenance cost and downtime of the equipment. Good Safety Performance: A variety of safety protection devices, such as overload protection and limit protection, are set to ensure the safety of operators and equipment. Scalability: According to different customer needs, relevant functional components, such as an automatic feeding device and an end pre-bending device, can be added or replaced to meet diverse production needs.
Performance Characteristics:
The structural type of this machine is an economical three-roll symmetric type. The upper roll moves vertically in the central symmetric position of the two lower rolls, which is achieved through the transmission of the screw-nut-worm. The two lower rolls rotate, and the output gear of the reducer meshes with the gear of the lower roll to provide torque for rolling the plate. The disadvantage of this machine is that the end of the plate needs to be pre-bent with the help of other equipment 主要技术参数：
本资料所列数据为参考数据，如与机床实际数据不符，应以机床实际数据为准，以上参数如有变动，恕不另行通知，本公司保留对此资料的最终解释权! Remarks: The data listed in this document are for reference only. In case of any discrepancy between these data and the actual data of the machine tool, the actual data of the machine tool shall prevail. The above parameters are subject to change without prior notice, and our company reserves the right to the final interpretation of this document!
|
